A ROBUST AND COST-EFFECTIVE 3D SCANNER

  TECH SPECS


MAXIMUM OBJECT SIZE: 165mm x 165mm

SCAN RESOLUTION: up to 0.1mm

TEXTURE RESOLUTION: 5MP

EXPORT FORMATS:
STL, OBJ, 3DS, PLY, XYZ, RUB
JPG, PNG ( textures )

LASERS: two 560nm lasers with extended focus depth

IMAGE SENSOR: Aptina MT9P006, 5MP, photo-mode *

CAMERA LENS: M12, aspheric

ILLUMINATION: 4 x 5630 1w LEDs

STEPS PER REVOLATION: 800

SUPPORTED PLATFORMS:
Windows, Mac OS, Linux

SCAN SPEED: 3-10 minutes ( depending on selected quality )

CONNECTIVITY:
USB 2.0 high speed interface ( cable included )

POWER INPUT:
12v, 1.5A ( adapter included )

* unlike our competitors who use simple web-cam modules running in video mode, we use an FPGA chip to control the image sensor, being able to snap an image only when needed. The difference is that a webcam's main priotity is to keep a steady frame-rate by secrificing image quality. Yet we are able to achieve the best image quality by using prolonged exposure.




  PRE-ORDER




EXPECTED TO SHIP BEFORE MAY 31, 2014
PLEASE VISIT UPDATES TO SEE PRODUCTION PROGRESS

RUBICON 3D SCANNER - 399 EUR
SHIPPING BY EMS CURIER SERVICE - 42.5 EUR
